AI assistant for Sparx Enterprise Architect — talk to your model

Yes. Loonar Compass is freeware: free of charge for any purpose, including professional and commercial use, on any number of computers. You may also pass it on to others — free of charge, complete and unchanged, together with the licence file.

The source code is public on GitHub, so you can see exactly what the application does with your model. It is source-available, not open source: modifying the application, creating derivative works, selling it or renting it out is not allowed. Read the licence.

The application is free. The assistant works with your own Claude API key from the Anthropic Console, and Anthropic bills its use to the account the key belongs to — pay as you go, by the amount of text the model reads and writes. Current prices are on Anthropic’s pricing page.

The model is always Claude Haiku 5.5 (claude-haiku-5-5); it is not a setting. “Max tokens” (10,000 by default) only caps the length of a single answer: you pay for the text actually generated.

Windows 10 and Windows 11, 64-bit. It is a native Windows desktop application and works together with Enterprise Architect installed on the same computer.

• Enterprise Architect installed on the same computer, with a valid licence. The assistant starts it in the background, where it takes one licence seat; it closes again after 10 minutes without work and when you close the application.
• The model in a PostgreSQL database that your computer can reach (server, port, database name, account). Models in files (.qea, .qeax, .eap, .eapx, .feap) and repositories in other databases are not supported.
• User security enabled in the model (Settings → Security → Enable Security), in “Require User Lock to Edit” mode.
• An EA user account for the assistant, with a password and edit rights — ideally a separate one, so that its changes and locks are easy to tell from yours.

The application does not check for a particular EA version or edition. What matters is that your Enterprise Architect can open this repository with security enabled.

No. By default (“Just for me”) the installer installs Loonar Compass for your user account only, in %LOCALAPPDATA%\Programs\Loonar Compass, and needs no administrator rights. If you choose “For all users of this computer” instead (in C:\Program Files\Loonar Compass), the installer asks for administrator rights.

The application itself always runs as a normal user, and every user has their own settings and conversations. If someone else approves an installation for all users with an administrator account, enter your configuration later in the application (Settings), not in the installer — otherwise it ends up in the administrator’s profile.

Because the installer of version 0.3 is not digitally signed yet (with a code signing certificate), so Windows does not know its publisher. Microsoft Defender SmartScreen may therefore show “Windows protected your PC” when you start it, and your browser may warn that the file is not commonly downloaded. The default installation for your user account needs no administrator rights, so no administrator prompt appears; only an installation for all users asks for them — and shows the publisher as unknown. A signed installer is planned and should follow soon. Until then:

• Download the installer only from loonar.eu or from the project’s releases on GitHub, over HTTPS.
• Compare its checksum with the SHA-256 shown next to the download button — in PowerShell: Get-FileHash .\LoonarCompass-Setup-0.3.exe.
• In the SmartScreen window, click “More info” and then “Run anyway”.

On Windows 11 with Smart App Control turned on, unsigned applications are blocked and cannot be started this way; in that case, please wait for the signed version.

It saves only what you allow, and only in the way Enterprise Architect allows:

• Approval modes: ask — you approve every save; plan — one approval per answer; auto — no questions, for test models. Publishing to Confluence always needs your approval, and the request says explicitly when an existing page will be replaced.
• Writes only through EA: the database is read in a read-only session; every change is made by Enterprise Architect under the assistant’s EA account, with that account’s permissions and locks. Objects locked by other users are left alone.
• Instructions only from you: the assistant is instructed to treat the content of attachments, documents and the model as data, not as instructions to follow.
• Audit log: every save, failed ones included, is recorded with time, account and result, and can be exported to Excel.
• Baselines: before deleting or substantially restructuring an existing package, the assistant is instructed to save a baseline of it first; you restore it in EA (Manage Baselines → Compare/Restore).

Still, deleting is permanent and AI can make mistakes — the application reminds you of this, so review the proposed changes before you approve them. For important models use ask mode and keep database backups — the application comes without warranty.

To answer, the assistant sends only what it needs to Anthropic’s Claude API (api.anthropic.com): your messages and attachments, remembered notes, the templates in use, and what it has read from the model in that conversation — the results of its database queries (names and descriptions of packages, elements, diagrams) and images of the diagrams it showed. Not the whole database. After a language change, memory and templates are also sent for translation.

Beyond that, data goes only where you send it: published pages to your Confluence; bug reports and newsletter sign-ups are e-mails you check and send yourself from your mail program. The application sends nothing to Loonar on its own. Before using it on company models, check your organisation’s rules and the data terms of your Anthropic account.

On your computer, in your Windows user profile — every user of the computer has their own:

• %APPDATA%\Loonar Compass: settings (app.properties), conversation history, attachments, assistant memory, document templates and the audit log.
• Windows Credential Manager: the Claude API key, the EA account password, the database password and the Confluence token. None of them is kept in plain text in the settings file.

The program itself is installed in %LOCALAPPDATA%\Programs\Loonar Compass by default, or in C:\Program Files\Loonar Compass when installed for all users.

Yes, wherever the application connects by itself:

• Claude API and Confluence: only over HTTPS. A Confluence address starting with http:// is accepted only for a server on the same computer (localhost).
• Model database (PostgreSQL): TLS, set with “Connection encryption” on the “2. Model database (PostgreSQL)” card in Settings: “Preferred” (default) — TLS whenever the server offers it, otherwise an unencrypted connection; “Required” — TLS or no connection; “Required, certificate verified” — TLS, and the server’s certificate and name are checked against the Windows certificate store, including your company’s certificates. “Preferred” and “Required” do not check the certificate. After “Save and test connection”, the application tells you whether the connection is encrypted. In app.properties the setting is db.sslmode = prefer, require or verify-full.

Tip for database administrators: with hostssl entries in pg_hba.conf, the server accepts only TLS connections from all clients. Enterprise Architect’s own connection to the database follows EA’s settings, not the application’s.

Allow these connections: HTTPS (port 443) to api.anthropic.com, your PostgreSQL server (port 5432 by default; a direct connection, not through the proxy) and, if you publish pages, your Confluence.

For HTTPS, the application uses the proxy set in the Windows Internet settings (system proxy). You can also set the HTTPS_PROXY or ALL_PROXY environment variable, e.g. http://proxy.example.com:8080 (exceptions in NO_PROXY); it takes precedence over the system proxy. Restart the application after a change. For basic authentication, the user name and password can be part of the address in that variable; automatic detection and configuration scripts (WPAD, PAC) and proxy sign-in with your Windows account (NTLM, Kerberos) are not supported.

HTTPS certificates are also checked against the Windows certificate store, so a company root certificate used for traffic inspection is accepted once it is installed in Windows.

English, Polish, German and French: the application and installer windows, the assistant’s answers, the default document templates, the user guide, the licence and the changelog. The installer starts with a language choice (English by default); later you change it in Settings, on the “4. Language and change approval” card.

The assistant answers in the application’s language unless you write to it in another one. Conversation history is never translated.

Yes, with both — and Confluence is optional. Without it, the assistant still prepares pages: you paste the code into the source editor yourself (“Copy page code”, “Open images folder”).

To publish directly, fill in the “6. Confluence” card in Settings: for Data Center the address and a personal access token; for Cloud the address (https://your-company.atlassian.net/wiki), the account’s e-mail and an API token; plus the space key and, optionally, a parent page. The assistant then creates or updates pages through the REST API, with diagrams as attachments — always after your approval (the request says explicitly when an existing page will be replaced; the previous version stays in the page history) and with the permissions of that token.

Close the application and run the installer of the newer version. It suggests the same folder, shows what has changed since your version and keeps your settings, conversation history, attachments, memory, templates and audit log; the key, passwords and tokens in Credential Manager stay as well. New versions are published here and on GitHub.

Close the application and use “Uninstall Loonar Compass” in the Start menu or its entry in Windows Settings → Apps → Installed apps. This removes the program files, the shortcuts and the system entry. Your data stays unless you tick one of these options:

• “Remove settings, conversations, attachments, memory, templates and the audit log” — this deletes the whole %APPDATA%\Loonar Compass folder;
• “Remove the API key, passwords and tokens from Credential Manager” — the Claude API key, the EA account and database passwords and the Confluence token.

Your EA model, files you saved elsewhere and pages published to Confluence are not affected.

In the application, open “Report a bug” in the navigation bar, describe what happened, add screenshots and click “Send report”: a ready e-mail to mariusz@loonar.eu opens in your default mail program, where you check it and send it. Technical information (application version, Windows version, AI model, approval mode, last message — no passwords or keys) is added only while that option is ticked (it is by default).

For release news, enter your e-mail on the “5. New releases (newsletter)” card in Settings and tick the consent. Or simply write to mariusz@loonar.eu.
